TRIDONIC driver LCA 35W 24V one4all SC PRE dimmable
Manufacturer
- Brand:
- TRIDONIC
- Item no.:
- 9053034
Colour & design
- Color:
- white
- Material:
- Plastic
Dimensions
- Length (in cm):
- 19.5
- Width (cm):
- 4.3
- Height (cm):
- 3.02
- Net weight (kg):
- 0.157
Light source
- Light bulb included:
- No
- Integrated LEDs:
- No
Electrical information
- IP code:
- IP20
- Supply voltage (volts):
- 230
Constant voltage LED driver LCA 24V one4all SC PRE IP20 from TRIDONIC, variable dimming options
This driver for 24V LEDs can be controlled via various protocols thanks to the one4all interface - DALI, DSI, switchDIM or corridorFUNCTION; it can also be configured via the network (ready2mains). The slimline LED driver can be used independently or integrated. Typical applications are cove lighting, façade accent lighting and indirect ceiling lighting.
- For installation in dry environments
- suitable for furniture construction (M/MM mark)
- Housing with strain relief
- Dimming range: 1 % to 100
- lumDATA: luminaire data, energy report, diagnosis and maintenance
- Ambient temperature during operation: - 25 °C to + 50 °C
- Control interfaces: one4all (DALI, DSI, switchDIM, corridorFUNCTION), ready2mains (configuration and dimming via mains)
- 45° plug-in terminals for connection
- Standards complied with: EN 55015, EN 61000-3-2, EN 61000-3-3, EN 61347-1, EN 61347-2-13, EN 62384, EN 61547, EN 62386-101/102/103, EN 50172 (suitable for central battery systems), EN 60598-2-22 (suitable for emergency lighting installations)
